13.1 Introduction to track smoothing

In any tracking system, there are three sources of noise that potentially affect the values of dependent variables such as Distance moved or Velocity:
System noise – The noisy output of tracking systems means that when you track an object that does not move, the position of the object irregularly oscillates between two or more locations. This way the track may show continuous movement of the object that corresponds to a real-world distance of, for example, 1 cm, while in fact the animal is sitting still. As a result, the data show that the immobile object traveled quite a distance.
Outliers resulting from tracking noise – Occasionally the tracking system generates a single outlier which obviously affects a dependent variable such as Velocity.
Small movements of the animal ('body wobble') – When you track a moving animal using a high sample rate, sideways movements from the wobbling of the animal's body are also tracked. This results in an overestimation of, for instance, the total distance moved.
EthoVision XT 10 has two track smoothing methods:
Smoothing (Lowess) - You should use Smoothing when you want to eliminate small movements, such as body wobbling during locomotion, that might affect dependent variables such as total distance moved. On the other hand, do not use Smoothing when you are specifically interested in small, erratic movements of the animal, for instance, when it has been treated with a drug such as amphetamine.
Minimal Distance Moved - Use Minimal Distance Moved when the animal sits still, yet the body points still move slightly due to system noise or breathing.

Please note that these two track smoothing methods affect the tracks after
      acquisition. In some cases you may already want to smooth the track during
acquisition. This may especially be the case if you use Trial and Hardware Control. As an example, if the centre point of an animal is detected in a zone, you want the pellet dispenser to drop a pellet. If the detected centre point is moving rapidly because of noise, this may result in a number of consecutive pellets to be dropped, every time the centre point crosses the border of the zone. Track smoothing does not solve this problem. Instead, use Track noise reduction in the detection settings to smooth the tracks during data acquisition (see page 223).

You can find these methods in the Experiment Explorer, under Track Smoothing Profiles (also from the Acquisition menu).



13.2 The Lowess smoothing method
The Lowess (Locally weighted scatter plot smoothing) method fits a curve to the dataset, using least square regression that is modified as follows:
The Lowess method uses a moving time window (or half size window) that contains a subset of sample points.
The Lowess method uses a 2-degree (non-linear) polynomial fit. This fit is applied to the center-point. If you use center-point, nose-point and tail-base detection, the fit is also applied to the angle between center-point and nose-point and between the center-point and tail-base. (see Notes below).
The Lowess method is weighted; sample points nearest to the point being fitted have a larger influence on the fit than sample points further away.
The Lowess method has been successfully applied on track data from EthoVision.

Procedure
To apply Lowess smoothing to your acquired track data:
1. Open a Track Smoothing Profile (see also “Managing settings and profiles” on page 663).
2. Select the Smoothing (Lowess) check box and click the Edit button.
3. Change the number of sample points in the half window size list.
- The default value is 10 which is the recommended value. Selecting a larger half window size results in a smoother path. Selecting a smaller half window size results in a path that more resembles the original path. With a lower sample rate, you should use a larger half window size to get the same smoothing as with a higher sample rate.


Notes
For more information on the Lowess method, see the web page http://en.wikipedia.org/wiki/Lowess. and the White Paper about smoothing on the EthoVision XT download page on www.noldus.com.
For more information on the application of the Lowess method on EthoVision track data, see Drai and Golani, 2001, SEE: a tool for the visualization and analysis of rodent exploratory behavior, Neurosci. & Biobehav. Rev. 25(5): 409-426 and Kafkafi et al., 2005, Genotype-environment interactions in mouse behavior: a way out of the problem, Proc. Natl. Acad. Sci. USA, 102(12): 4619-4624.
Smoothing is applied after data acquisition but before the Minimal Distance Moved method.
Smoothing is applied to the center-point, and subsequently to the angle between the center-point and the nose-point (if you also track nose-point and tail-base).
Applying Smoothing does not change the acquired data.
When a sample is missing, it is first interpolated using the usual rules (see Chapter 12), then its X-Y coordinates are re-calculated according to Lowess.
When you have edited your data, Smoothing is applied to the edited data.
When you have applied Smoothing, the smoothed data are used for analysis and for export.
Samples assigned to a hidden zone are smoothed too. For this reason, after smoothing with the Lowess method, part of the samples in the hidden zone are “moved” outward, producing the effect shown in Figure 13.1. Those samples add up to the total distance moved in your results (the segments between adjacent points in Figure 13.1). How many samples are moved depends on the original trajectory.

Figure 13.1 An example of the effect of Lowess smoothing on the location of samples originally assigned to a hidden zone. The arrow represents the direction of movement (that is, the animal entered the hidden zone). After smoothing, part of the samples assigned to the hidden zone center are moved toward the adjacent samples outside the zone. A similar effect can be seen when the animal exits the hidden zone.

Acknowledgment
We gratefully acknowledge the ongoing collaboration with Prof. Ilan Golani, Prof. Yoav Benjamini and their colleagues at Tel Aviv University. Their pioneering work on the detailed analysis of animal movement has been a source of inspiration for the developers of EthoVision and for many of its users around the world.

13.3 The Minimal Distance Moved method
With the Minimal Distance Moved method, you can pick out the data when the subject moved a minimal distance from one sample to the next. For example, when the distance moved between the current and the previous sample is above (or equal to) the threshold for Minimal Distance Moved, the current sample is used for analysis. If the distance moved between the current and the previous sample does not exceed the threshold, the previous sample is used for analysis.



In contrast to the Minimal Distance Moved method used in EthoVision XT 7, in        EthoVision XT 10, no samples are excluded for analysis.
Minimal Distance Moved is only applied to the center-point.
Under some circumstances, using the Minimal Distance Moved filter might affect dependent variables other than Distance Moved and Velocity. To apply Minimal Distance Moved to some dependent variables, not others, create two Track Smoothing profiles: one with Minimal Distance Moved selected, the other without Minimal Distance Moved selected. Run analysis twice, using first one Track Smoothing profile, then the other one.

Procedure
1. Open a Track Smoothing Profile (see also “Managing settings and profiles” on page 663).
2. Select the Minimal Distance Moved check box and click the Edit button.

3. Under Select, enter the Minimal Distance Moved threshold (in centimeters).
4. Next, choose one of the two options:
- Direct (A > MDM) – To select samples on the basis of the shortest distance (beeline distance) between samples. Select Direct to exclude movements such as breathing, when the animal is sitting still.

- Along the path (B + C + D > MDM) – To select samples on the basis of the actual path between samples. Select Along the path whenever you want to filter samples according to the distance moved along the path.
See Figure 13.2 for an example.
5. Click OK.

Direct vs. Along the path Minimal Distance Moved
Direct (left-hand side in Figure 13.2) – The program calculates the shortest distance between a sample and the next (A-B). If this distance is shorter than the threshold distance, sample B is set to sample A. Then the program calculates the distance to the second next sample (A-C), etc. until it finds a segment (A-D) longer than the threshold distance. In this example, samples B and C are both set to sample A. This procedure is then repeated from sample D up to the end of the track.


Figure 13.2 Difference between the two options for the Minimal Distance Moved method: Direct (left) and Along the path (right). Top: A, B, ... E are the center-points of a subject along a track. The horizontal bar at the top (MDM) represents the threshold distance set in the procedure. The full segments represent the original (unfiltered) distance moved. The dotted segments are the distances calculated to find a sample with distance greater than the threshold.
In both cases, all five samples are selected for analysis, however their coordinates are different. Some samples are “moved” to a previous sample in such a way that their own value of distance moved is zero. In the case of “Direct”, samples B and C are set to overlap with A, and E is set to D. In the case of “Along the path”, samples B is set to A, and D to C. The resulting total distance moved is the line connecting the hatched squares. See also the text.

Along the path (right in Figure 13.2) – The program calculates the distance between a sample and the next (A-B). If this distance is shorter than the distance threshold, sample B is set to sample A. Then the program calculates the cumulative distance to the second

next sample (A-B + B-C, etc.) In this example, sample B is set to sample A, and sample D is set to sample C. The procedure is repeated from sample C up to the end of the track.
As shown by the case of Distance moved in the figure above, calculation of the dependent variables is affected by what Minimal Distance Moved option you choose.

Chapter 14

Introduction to Data Analysis

14.1 Overview of data analysis 410
Lists the functions for data preparation and output calculation, and explains important concepts.
14.2 Analysis advisor 413
A key to obtain results by combining data selection and the right dependent variables.
14.3 The Data Profiles screen 422
With the general procedure to select data.
14.4 A simple analysis: Results per zone 430
How to get basic results with a few mouse clicks.

14.1 Overview of data analysis
analysis functions

For data preparation:
Data Profiles — For choosing the data points subject to analysis. You can filter tracks, create groups, select specific time periods or track segments, etc.
Analysis Profiles — For choosing the behavioral endpoints, like speed, distance moved, time spent in a zone, etc.

For the analysis results:
Statistics and Charts — For obtaining a table with summary statistics of the dependent variables per trial and summary statistics and charts per group of trials.
Track Visualization — For visualizing data as tracks plotted over a static background video image
Heatmap Visualization — For visualizing the location where your animals spent most time.
Integrated Visualization — For visualizing the track together with video, and plotting dependent variables against time.
Export (Raw Data and Statistics) — To export raw data, dependent variables and their summary statistics.

dependent variables and statistics
Dependent variables
In EthoVision XT, a Dependent variable is the variable quantifies the behavior of a subject or marks an event occurred in a trial.
Example 1 – To quantify locomotor activity, choose ‘Distance moved’, or ‘Velocity’ as Dependent variables.
Example 2 – To quantify spatial orientation behavior, choose ‘Heading’ as a Dependent variable.
Example 3 – To calculate how many food pellets were dropped by a pellet dispenser, choose ‘Hardware continuous variable’ as a Dependent variable.
Dependent variables are calculated for each sample of the track data. The table below shows the Distance moved calculated for a few samples. X and Y are the coordinates of the center of the subject's body. Sample rate = 12.5 samples/s.

Time X Y Distance moved
0 -8.7393 -26.1678
0.08 -6.8267 -26.9699 2.0740
0.16 -4.7220 -27.0748 2.1074
0.24 -3.2380 -26.6227 1.5513

Some dependent variables have discrete values. For example, In zone or Mobility. The following table shows the In zone variable calculated for a few samples. In zone=1, Not in zone=0. The subject's center point enters zone 1 at 0.16 s.

Time X Y In zone (Zone 1)
0 -8.7393 -26.1678 0
0.08 -6.8267 -26.9699 0
0.16 -4.7220 -27.0748 1
0.24 -3.2380 -26.6227 1

You can plot the values of any dependent variable against time (see page 521). For a detailed description of the dependent variables, see page 571.

Statistics
In EthoVision XT, Statistics are descriptive statistics of the per-sample values of a Dependent variable.
Example 1 – To quantify locomotor activity, choose the Total statistic for the dependent variable Distance moved. Choose the Mean statistic for the dependent variable Velocity.
The Total distance moved is the sum of the per-sample values of distance. In the example of the table above, the total is 5.73 cm.
Example 2 – To quantify spatial orientation behavior, choose the Mean and Standard deviation statistics for the dependent variable Heading.
In EthoVision XT, each dependent variable has its own set of statistics available.
Trial Statistics — Statistics calculated per trial.
Example – When you choose Total as a Trial Statistic for the dependent variable Distance moved, and your experiment contains 100 trials of one animal in one arena, you obtain 100 values of Total Distance moved.
Group Statistics — Summary statistics of the Trial Statistics, calculated over all the trials selected in your data profile. This is useful when you define groups of trials (or tracks; see page 440).
Example – You have defined two groups of tracks, Treated and Saline, and you want to calculate the Mean and Standard deviation of Distance moved and other variables per group.
For the complete list of statistics, see page 540.

In general, the analysis results depend on a few factors:
Whether you applied Noise reduction during acquisition;
Whether the tracks are smoothed, and how;
Which tracks and data points are selected in the current Data profile.
Which dependent variables and statistics are selected in the current Analysis profile.

14.2 Analysis advisor


What do you want to do?

Simple calculations
(e.g. total distance moved) — See below.



Analysis in relation to time — page 419

Zone visits — page 414. Analysis of sequences — page 419 Other analyses with zones — page 415 Analysis of groups of tracks — page 421
Note — In the next sections “Analysis profile” and “Data profile” indicate that you can either open an existing profile, or create a new one.

simple calculations (e.g. total distance moved)
1. Optional — Smooth the tracks to get more realistic measures of distance (Chapter 13).
2. In the Experiment Explorer, click an Analysis profile, and then click the button next to the dependent variable (for example, Distance moved). In the Trial Statistics tab, select the statistics you want to calculate (for example, Total).
3. In the Experiment Explorer, click Statistics and Charts, then Calculate.


zone visits
Number of entries and time spent in specific zones
1. In the Analysis profile, under Location, click the button next to In zone. Specify the zones you are interested in. In the Trial Statistics tab, select Frequency (for zone entries) and Cumulative Duration (for time spent).
2. Click Statistics and Charts, then Calculate.

Number of entries and total time spent in two or more zones
If you want to group results for two or more zones, like the open arms of a plus maze:

1. In step 1 above, specify the zones you are interested in, and make sure that When in any of the selected zones is selected. In the Trial Statistics tab, select Frequency and Cumulative Duration.
2. Click Statistics and Charts, then Calculate.

Alternatively, in the Arena Settings make a Cumulative zone from the selected       zones (see page 133) and calculate the frequency and cumulative duration in this
zone.

Number of entries and time spent in an intersection of zones
When two zones are defined in different layers, it is possible to analyze their intersection. In this example, the intersection of the quadrant “North-West” and the annulus-shape “Maze border”.
1. In the Analysis profile, under Location, click the button next to In zone. Specify the zones you are interested in, and make sure that When in all selected zones is selected. In the Trial Statistics tab, select Frequency and Cumulative Duration.
2. Click Statistics and Charts, then Calculate.
For information on how to organize zones in layers (groups), see page 129 and an example in Figure 6.5.

other analyses with zones
Path length and speed for specific zones

In this case you calculate dependent variables for track segments. First, you specify the track segments When in zone with a Data profile and then you choose the dependent variables in an Analysis profile.
1. In the Data profile, in the Result box, click the Settings button and then select Results per zone. Specify the zones you are interested in.

For more information see page 430.
2. In the Analysis profile, click the button next to the dependent variable you require, e.g Distance moved or Velocity. In the Trial Statistics tab, select the statistic (e.g., Total for distance moved and Mean for velocity).
3. Click Statistics and Charts, then Calculate.

Path length and speed for a combination of zones
1. In the Data profile, in the Components pane, click the button next to Nesting - In zone. Specify the zones you are interested in. Select the option that you require:
- When in any of selected zones to analyze when the animal was in one or another zone.
- When in all selected zones to analyze when the animal was in all the zones simultaneously. This assumes that the zones are at least partially overlapping: for instance, a quadrant and a border zone in a water maze. If zones are not overlapping, data are not selected since the subject’s body points cannot be in two non-overlapping zones at the same time.
For more information, see page 450.
2. In the Analysis profile, click the button next to the dependent variable (e.g. Velocity), then click Add.
3. Click Statistics and Charts, then Calculate.

Distance traveled or time before entering a zone
For example, in a Barnes maze or Water maze test. You want to calculate the Total distance moved before the animal enters a zone. In a Data Profile, select the track segment before the first zone visit, and in an Analysis profile specify the Dependent variable Distance moved.

For distance traveled:
1. In the Data profile, in the Components pane, click the button next to Nesting - Latency to zone. Specify 1st visit, the zone and keep Interval before zone visit selected.

2. In the Analysis profile, click the button next to the Distance moved. In the Trial Statistics
tab, select Total, then click Add.
3. Click Statistics and Charts, then Calculate. For time:
If you want to know the time before the animal enters a zone, you do not need a Data profile.
1. In the Analysis profile, click the button next to the In zone. Choose the zone and in the
Trial Statistics tab, select Latency to first, then click Add.
2. Click Statistics and Charts, then Calculate.

Which zone has been visited first by the animal
For example, in a dual choice test, in a T maze, leaf disc, or a Y-maze, etc.
1. In the Analysis profile, specify the dependent variable In zone. In the Trial Statistics tab, select Latency to first, then click Add.
2. Click Statistics and Charts, then Calculate.
3. Under Export, click Statistics. In the exported file check which zone has a lower Latency value.

Where a behavior occurred
The term “Behavior” here may indicate a state like Movement, Mobility, Activity, Body elongation, behaviors scored manually, or behaviors detected automatically.

Unitrans世联翻译公司在您身边,离您近的翻译公司,心贴心的专业服务,专业的全球语言翻译与信息解决方案供应商,专业翻译机构品牌。无论在本地,国内还是海外,我们的专业、星级体贴服务,为您的事业加速!世联翻译公司在北京、上海、深圳等国际交往城市设有翻译基地,业务覆盖全国城市。每天有近百万字节的信息和贸易通过世联走向全球!积累了大量政商用户数据,翻译人才库数据,多语种语料库大数据。世联品牌和服务品质已得到政务防务和国际组织、跨国公司和大中型企业等近万用户的认可。 专业翻译公司,北京翻译公司,上海翻译公司,英文翻译,日文翻译,韩语翻译,翻译公司排行榜,翻译公司收费价格表,翻译公司收费标准,翻译公司北京,翻译公司上海。
  • “贵司提交的稿件专业词汇用词准确,语言表达流畅,排版规范, 且服务态度好。在贵司的帮助下,我司的编制周期得以缩短,稿件语言的表达质量得到很大提升”

    华东建筑设计研究总院

  • “我单位是一家总部位于丹麦的高科技企业,和世联翻译第一次接触,心中仍有着一定的犹豫,贵司专业的译员与高水准的服务,得到了国外合作伙伴的认可!”

    世万保制动器(上海)有限公司

  • “我公司是一家荷兰驻华分公司,主要致力于行为学研究软件、仪器和集成系统的开发和销售工作,所需翻译的英文说明书专业性强,翻译难度较大,贵司总能提供优质的服务。”

    诺达思(北京)信息技术有限责任公司

  • “为我司在东南亚地区的业务开拓提供小语种翻译服务中,翻译稿件格式美观整洁,能最大程度的还原原文的样式,同时翻译质量和速度也得到我司的肯定和好评!”

    上海大众

  • “在此之前,我们公司和其他翻译公司有过合作,但是翻译质量实在不敢恭维,所以当我认识刘颖洁以后,对她的专业性和贵公司翻译的质量非常满意,随即签署了长期合作合同。”

    银泰资源股份有限公司

  • “我行自2017年与世联翻译合作,合作过程中十分愉快。特别感谢Jasmine Liu, 态度热情亲切,有耐心,对我行提出的要求落实到位,体现了非常高的专业性。”

    南洋商业银行

  • “与我公司对接的世联翻译客服经理,可以及时对我们的要求进行反馈,也会尽量满足我们临时紧急的文件翻译要求。热情周到的服务给我们留下深刻印象!”

    黑龙江飞鹤乳业有限公司

  • “翻译金融行业文件各式各样版式复杂,试译多家翻译公司,后经过比价、比服务、比质量等流程下来,最终敲定了世联翻译。非常感谢你们提供的优质服务。”

    国金证券股份有限公司

  • “我司所需翻译的资料专业性强,涉及面广,翻译难度大,贵司总能提供优质的服务。在一次业主单位对完工资料质量的抽查中,我司因为俄文翻译质量过关而受到了好评。”

    中辰汇通科技有限责任公司

  • “我司在2014年与贵公司建立合作关系,贵公司的翻译服务质量高、速度快、态度好,赢得了我司各部门的一致好评。贵司经理工作认真踏实,特此致以诚挚的感谢!”

    新华联国际置地(马来西亚)有限公司

  • “我们需要的翻译人员,不论是笔译还是口译,都需要具有很强的专业性,贵公司的德文翻译稿件和现场的同声传译都得到了我公司和合作伙伴的充分肯定。”

    西马远东医疗投资管理有限公司

  • “在这5年中,世联翻译公司人员对工作的认真、负责、热情、周到深深的打动了我。不仅译件质量好,交稿时间及时,还能在我司资金周转紧张时给予体谅。”

    华润万东医疗装备股份有限公司

  • “我公司与世联翻译一直保持着长期合作关系,这家公司报价合理,质量可靠,效率又高。他们翻译的译文发到国外公司,对方也很认可。”

    北京世博达科技发展有限公司

  • “贵公司翻译的译文质量很高,语言表达流畅、排版格式规范、专业术语翻译到位、翻译的速度非常快、后期服务热情。我司翻译了大量的专业文件,经过长久合作,名副其实,值得信赖。”

    北京塞特雷特科技有限公司

  • “针对我们农业科研论文写作要求,尽量寻找专业对口的专家为我提供翻译服务,最后又按照学术期刊的要求,提供润色原稿和相关的证明文件。非常感谢世联翻译公司!”

    中国农科院

  • “世联的客服经理态度热情亲切,对我们提出的要求都落实到位,回答我们的问题也非常有耐心。译员十分专业,工作尽职尽责,获得与其共事的公司总部同事们的一致高度认可。”

    格莱姆公司

  • “我公司与马来西亚政府有相关业务往来,急需翻译项目报备材料。在经过对各个翻译公司的服务水平和质量的权衡下,我们选择了世联翻译公司。翻译很成功,公司领导非常满意。”

    北京韬盛科技发展有限公司

  • “客服经理能一贯热情负责的完成每一次翻译工作的组织及沟通。为客户与译员之间搭起顺畅的沟通桥梁。能协助我方建立专业词库,并向译员准确传达落实,准确及高效的完成统一风格。”

    HEURTEY PETROCHEM法国赫锑石化

  • “贵公司与我社对翻译项目进行了几次详细的会谈,期间公司负责人和廖小姐还亲自来我社拜访,对待工作热情,专业度高,我们双方达成了很好的共识。对贵公司的服务给予好评!”

    东华大学出版社

  • “非常感谢世联翻译!我们对此次缅甸语访谈翻译项目非常满意,世联在充分了解我司项目的翻译意图情况下,即高效又保质地完成了译文。”

    上海奥美广告有限公司

  • “在合作过程中,世联翻译保质、保量、及时的完成我们交给的翻译工作。客户经理工作积极,服务热情、周到,能全面的了解客户的需求,在此表示特别的感谢。”

    北京中唐电工程咨询有限公司

  • “我们通过图书翻译项目与你们相识乃至建立友谊,你们报价合理、服务细致、翻译质量可靠。请允许我们借此机会向你们表示衷心的感谢!”

    山东教育出版社

  • “很满意世联的翻译质量,交稿准时,中英互译都比较好,措辞和句式结构都比较地道,译文忠实于原文。TNC是一家国际环保组织,发给我们美国总部的同事后,他们反应也不错。”

    TNC大自然保护协会

  • “原英国首相布莱尔来访,需要非常专业的同声传译服务,因是第一次接触,心中仍有着一定的犹豫,但是贵司专业的译员与高水准的服务,给我们留下了非常深刻的印象。”

    北京师范大学壹基金公益研究院

  • “在与世联翻译合作期间,世联秉承着“上善若水、厚德载物”的文化理念,以上乘的品质和质量,信守对客户的承诺,出色地完成了我公司交予的翻译工作。”

    国科创新(北京)信息咨询中心

  • “由于项目要求时间相当紧凑,所以世联在保证质量的前提下,尽力按照时间完成任务。使我们在世博会俄罗斯馆日活动中准备充足,并受到一致好评。”

    北京华国之窗咨询有限公司

  • “贵公司针对客户需要,挑选优秀的译员承接项目,翻译过程客户随时查看中途稿,并且与客户沟通术语方面的知识,能够更准确的了解到客户的需求,确保稿件高质量。”

    日工建机(北京)国际进出口有限公司

15811068017

15801211926

18801485229
点击添加微信

无需转接等回电
